Start a RethinkDB server

    Want to start instances of RethinkDB on system startup? See Start RethinkDB at system startup to learn how to set up RethinkDB with init.d or systemd.

    This document describes how to start RethinkDB from the command line in several configurations, from a single instance on one machine to multiple instances on multiple machines.

    Starting the server

    To start the first RethinkDB instance, run this command in your terminal:

    $ rethinkdb
    info: Creating directory /home/user/rethinkdb_data
    info: Listening for intracluster connections on port 29015
    info: Listening for client driver connections on port 28015
    info: Listening for administrative HTTP connections on port 8080
    info: Server ready


    Note the port numbers you can use to access RethinkDB:

    • Use the intracluster port (29015 by default) to connect other nodes in the cluster to this node.
    • Point your browser to the HTTP connections port (8080 by default) to access the web interface.

    For a complete list of options that can be passed to RethinkDB on the command line, read RethinkDB command line options or type rethinkdb --help at the terminal prompt.

    Multiple RethinkDB instances on a single machine

    Adding a node to a RethinkDB cluster is as easy as starting a new RethinkDB process and pointing it to an existing node in the cluster. Everything else is handled by the system without any additional effort required from the user.

    Now start the second RethinkDB instance on the same machine:

    $ rethinkdb --port-offset 1 --directory rethinkdb_data2 --join localhost:29015
    info: Creating directory /home/user/rethinkdb_data2
    info: Listening for intracluster connections on port 29016
    info: Attempting connection to 1 peer...
    info: Connected to server "Chaosknight" e6bfec5c-861e-4a8c-8eed-604cc124b714
    info: Listening for client driver connections on port 28016
    info: Listening for administrative HTTP connections on port 8081
    info: Server ready


    You now have a RethinkDB cluster! Try pointing your browser to localhost:8080 or localhost:8081 to access the web interface. If you click on the “Servers” tab at the top, you should see both servers in the cluster.

    You can also point the client drivers to localhost:28015 or localhost:28016 to start running queries (it doesn’t matter which node you use—the cluster will automatically route all commands to appropriate nodes).

    Note the command line parameters we used to start the second node:

    • --port-offset—increment all ports by 1 so the two nodes don’t try to use the same ports on one machine.
    • --directory—use a different data directory so the two nodes don’t try to access the same files.
    • --join—tell our new RethinkDB instance to connect to another instance (in this case, localhost:29015).

    For a complete list of options that can be passed to RethinkDB on the command line, read RethinkDB command line options, or type rethinkdb --help at the terminal prompt.

    Having trouble accessing the web interface? Try restarting both of your RethinkDB instances with an additional --bind all parameter.

    In production, you’d likely want to specify options via configuration files rather than command line options; read the configuration file documentation for details on the format and available options. Also, you’d want your RethinkDB instances to come online at system startup. See Start RethinkDB at system startup to learn how to set up RethinkDB with init.d or systemd.

    Want to connect a third node? You can join it with either of the two existing nodes in the cluster.

    A RethinkDB cluster using multiple machines

    Starting a cluster on multiple machines or VMs is even easier than starting it on a single machine, because you don’t have to worry about port and directory conflicts.

    First, start RethinkDB on the first machine:

    $ rethinkdb --bind all


    Then start RethinkDB on the second machine:

    $ rethinkdb --join IP_OF_FIRST_MACHINE:29015 --bind all


    You now have a RethinkDB cluster!

    Note that by default, RethinkDB only opens connections bound to localhost in order to prevent unauthorized clients on the network from connecting to the server. The --bind all option allows connections from anywhere on the network. It works well if the network is protected.

    If your network is open to the internet, you should take additional precautions. See the security page for more details.

    Troubleshooting

    Seeing a ‘received invalid clustering header’ message? RethinkDB uses three ports to operate—the HTTP web UI port, the client drivers port, and the intracluster traffic port. You can connect the browser to the web UI port to administer the cluster right from your browser, and connect the client drivers to the client driver port to run queries from your application. If you’re running a cluster, different RethinkDB nodes communicate with each other via the intracluster traffic port.

    The message received invalid clustering header means there is a port mismatch, and something is connecting to the wrong port. For example, it’s common to get this message if you accidentally point the browser or connect the client drivers to the intracluster traffic port.
